Introduction

It is generally accepted that maintaining the vitality of all or part of dental pulp is important, especially in traumatic teeth or those with an incomplete root [ 1 ]. Direct pulp capping (DPC) is a successful method for maintaining pulp vitality. During the DPC, the exposed pulp tissue is covered with a pulp-capping material to preserve its function and biological activities and to protect it from additional injury [ 2 , 3 ]. The success of DPC treatment is influenced by various factors such as patient's age, periodontal condition, root formation stage, pulp exposure dimensions and nature (traumatic, mechanical or caries), microbial contamination of exposed area, pulp status, and types and properties of pulp-capping materials as well as sealing ability of restorative materials [ 4 , 5 ]. Studies have shown that dental pulp healing after DPC is directly related to the properties of pulp-capping materials, including sealing ability, antimicrobial activity, biocompatibility, and the dentin bridge formation [ 6 , 7 ]. Over the past few years, various materials such as calcium hydroxide, biologically active molecules, Biodentine, calcium enriched mixture (CEM) and mineral trioxide aggregate (MTA) have been used for pulp capping [ 2 ]. MTA was introduced in 1993 by Torabinejad, which is the material of choice for conservative pulp therapy, apexification, and perforation repair [ 8 ]. MTA is composed of tricalcium phosphate, tricalcium aluminate, tricalcium oxide, silicate oxide, and several other oxides that are used in small amount in the composition of this substance [ 9 ]. A study has demonstrated excellent results for the MTA when used as a pulp capping material [ 10 ]. The desirable properties of MTA include excellent seal, high biocompatibility, low cytotoxicity, calcium ion release, and also its high alkalinity that provides its bactericidal properties. This material is not affected by contamination with blood or tissue fluids [ 4 , 10 , 11 ]. On the other hand, its unfavorable properties include delayed setting time, tooth staining over time, poor handling characteristics, and high costs [ 4 , 10 ].

CEM cement was first introduced as a root-end filling material. The main components of the cement powder are calcium oxide (CaO), sulfur trioxide (SO₃), phosphorus pentoxide (P₂O₅) and silicon dioxide (SiO₂) [ 12 , 13 ]. CEM cement is an effective antibacterial and antifungal agent and induces dentinogenesis, osteogenesis, and cementogenesis [ 6 ]. The CEM cement creates an environment with high pH value (about 11) and simultaneously releases high amounts of calcium and phosphorus ions, which facilitates the formation of hydroxyapatite [ 6 , 10 ]. The sealing ability and biocompatibility properties of CEM cement are similar to the MTA [ 10 ]. The CEM cement compared to the MTA has shorter setting time (less than an hour), similar pH, greater flow, less film thickness, good handling characteristics and no tooth discoloration [ 14 , 15 ].

Biodentine is also a new calcium silicate-based material, which has the same properties as the MTA, although it has resolved some of the problems of this material (setting time and staining) [ 16 , 17 ]. A study has shown that Biodentine has a positive effect on pulp cells and induces the formation of restorative dentin similar to MTA [ 16 ]. Biodentine has several good properties including good sealing ability, proper compressive strength, short setting time, and bioactivity. According to the manufacturer, this material has less setting time (around 12 minutes) than two other substances, which allows the placement of permanent restoration in shorter time [ 18 ].

Tabarsi et al. [ 14 ] examined the response of dental pulps in dogs to three pulp‐capping materials (MTA, CEM, and calcium hydroxide) and showed that there was no significant difference between CEM and MTA in terms of dentin bridge formation, pulp vitality, and lack of inflammation.

Nowicka et al. [ 16 ] evaluated the dentin bridge formation after direct capping with calcium hydroxide, MTA, Biodentine, and Single Bond Universal in human teeth and reported the maximum thickness of the dentin bridge was found when Biodentine was employed; they found no significant difference between the MTA and Biodentine in term of dentin bridge formation.

Zarrabi et al. [ 15 ] compared the response of human dental pulps to MTA and CEM when used as pulp capping material and showed that CEM cement compared to the MTA provided a thicker dentin bridge, but their difference was not significant.

Despite the extensive research on pulp capping, previous studies have not yet used all of these materials (MTA, CEM cement, and Biodentine) in a clinical trial study and there is no complete comparison of these materials. Therefore, the aim of this clinical trial study was to compare the histological response of human dental pulp after direct pulp capping with three materials of MTA, CEM cement, and Biodentine.

Materials and Method

The present randomized clinical trial study was conducted on 40 human first and second maxillary and mandibular premolar teeth without restoration, periodontal disease and caries, with healthy pulp from patients aged 14-25 years that were scheduled for extraction for orthodontic treatment. All clinical procedures were performed based on the Ethics Committee of Kerman University of Medical Sciences (Code of Ethics: IR.KMU.REC.1395.549 and IRCT code: IRCT2017091 728804N2).

Radiography was taken from each tooth at the baseline to rule out the possibility of any periapical lesions and proximal caries. The pulp vitality test was performed at the baseline by cold test and electric pulp tester. At the beginning, the teeth were divided into four groups, namely as (1) MTA group: pulp capping with MTA (Angelus-Brazil), (2) CEM cement group: pulp capping with CEM cement (Bionique Dent-Iran), (3) Biodentine group: pulp capping with Biodentine (Septodent-England), and finally (4) Control group.

After local anesthesia with 2% lidocaine (Persocaine-E, Darou Pakhsh Co., Tehran, Iran), the teeth were isolated with a rubber dam, and then polished slowly with a rubber cup and prophylaxis paste, and disinfected by 0.2% chlorhexidine (Iran NAJO Pharmaceutical Co.). The class V cavities were prepared on the buccal surfaces of teeth using diamond straight fissure bur #57 (Diatech-Switzerland) in a high-speed handpiece (NSK, Tokyo, Japan) with copious water spray. The standard class V cavity was prepared with dimensions of 3mm of occlusogingival height, 5mm of mesio-distal width and axial wall depth at exposure limit of 0.5mm in diameter. The preparations were cut 1mm above the free gingiva. The pulp capping material was prepared according to the manufacturer's instructions, and then placed on the exposed pulp of the teeth according to their specified group. Then, the cavities were filled with resin modified glass ionomer (VOCO, Germany) in all groups. All procedures were performed by the same operator.

In order to ensure the pulp vitality, the teeth were tested by the cold testing and electric pulp tester in 3 and 6 weeks after intervention. At the end of the 6th week (23,35), the teeth were extracted by premolar forceps without surgery and trauma. The extracted teeth were washed under sterilized water to remove blood and saliva. Then, the teeth were placed in 10% formalin (Merck, Germany) for 24 hours. After that, they were transferred into 15% nitric acid (Merck, Germany) for decalcification. The acid container was renewed daily, and the process continued to soften the tooth for the histological slide preparation process. The teeth were cut parallel to the longitudinal axis of the cavities, and placed in a special basket, and subsequently in the Tissue Processor (START-Japan). Then the paraffin blocks were prepared and 5 µm slices were cut from blocks by a microtome (Scilab-England). The sections were stained by hematoxylin and eosin (H & E) staining method and were evaluated using an optical microscope (Olympus-Japan) with a magnification of 400X.The evaluation was performed by a blinded pathologist.

The criteria evaluated were the inflammatory response, necrosis, dentin bridge formation, dentin bridge thickness, and the type of inflammation. The grading scales for the inflammatory response were considered as (0): no inflammation (0-25 inflamed cells at the magnification of 400X), (1): mild inflammation (26-50 inflamed cells at the magnification of 400X), (2): moderate inflammation (51-75 inflamed cells at the magnification of 400X), and (3) severe inflammation (76-100 inflamed cells at the magnification of 400X).

The assessment for necrosis was graded as (0) for absence of necrosis, and (1) for presence of necrosis. Moreover, for dentin bridge formation the scale was (0) for absence of dentin bridge, and (1) for dentin bridge deposition beneath the exposure area; for dentin bridge thickness, the mean diameter of the dentin bridge formed in three regions in terms of microns was measured. The inflammation type was graded as (1) for chronic inflammation, and (2) for acute inflammation.

Data were analyzed by SPSS version 21 using Kruskal-Wallis and Mann Whitney U tests. The significance level was considered to be at p< 0.05.

Results

Two teeth were excluded; one because of the root fract-ure during the tooth extraction and another one during histological preparation. Finally, 38 teeth were evaluate-d 9 in the MTA group, 9 in the CEM cement group, 10 in the Biodentine group and 10 in the control group. The results of evaluated criteria in different groups are summrized in Table 1. In all samples the pulp was vital. In the control group, mild chronic inflammation was found in 40% of samples. The formation of secondary dentin, similar to the dentin bridge, was found in only two samples (20%). In the MTA group, dentin bridge formation was detected in five samples (55.6%) and none of the specimens showed inflammation (Figure 1). In the CEM cement group, 22.2% of the samples showed mild inflammation and 11.1% showed moderate inflammation. The dentin bridge was formed in 66.7% of the samples (Figure 2). In the Biodentine group, mild and moderate inflammation were found in 60% and 30% of the samples respectively. The dentin bridge for-mation was detected in eight samples (80%) (Figure 3).

Figure 1. Pathologic image of a sample pulp capped with MTA: A (MTA material), B (calcified bridge), C (pulp hyperemia)

Figure 2. Pathologic image of a sample pulp capped with CEM cement: A (calcified bridge), B (pulp hyperemia), C (CEM material)

Figure 3. Pathologic image of a sample pulp capped with Biodentine: A (Biodentine material), B (microorganism), C (calcified bridge), D (pulp hyperemia), E (dentin)

The results of statistical analysis showed that the pulpal inflammation observed in the Biodentine group was significantly higher than all groups (p= 0.001).

The dentin bridge formation in CEM cement and Biodentine groups were significantly higher than the control group (p= 0.045 and p= 0.009, respectively), but the difference was not significant between MTA and CEM, and MTA and Biodentine, CEM and Biodentine groups(p= 0.63, p= 0.26 and p= 0.52, respectively). Statistical analysis showed that the mean thickness of dentin bridge was significantly higher in the Biodentine group than that of MTA and control groups (p= 0.035, p= 0.011 respectively). But there was no significant difference between the other groups (p= 0.09).

Discussion

The present clinical trial study was performed to evaluate the histological response of the human dental pulp to MTA, CEM cement, and Biodentine when used as direct pulp capping materials; the evaluated criteria were more comprehensive than those assessed in previous studies [ 5 , 16 , 19 ]. The main purpose of using the pulp capping materials is to cover pulp and preserve its vitality. In addition, the material’s effect on providing odontoblast-like cells by influencing dental pulp cells is an important factor for improving success rate of DPC [ 20 ]. The results of this study showed that no inflammatory response was observed in the MTA group, whereas Biodentine group showed significantly higher inflammation compared to either MTA, CEM cement or control groups. Tabarsi et al. [ 14 ] compared the pulp response during pulpotomy with MTA, CEM and calcium hydroxide in the teeth of dog, and showed that MTA and CEM were significantly better than calcium hydroxide in term of lack of inflammation, but there was no significant difference between CEM and MTA. Faraco and Holland [ 21 ] also reported no inflammation following DPC with MTA, which is consistent with the results of the present study.

One of the most important goals in pulp cap treatment is the reduction or absence of inflammation in the pulp. Less pulp inflammation may indicate the better biocompatibility of pulp-capping materials. [ 22 ] Therefore, induction of less inflammation can be considered as a success factor for pulp-capping materials, whereas dentin bridge formation alone does not prove the healthy status of the pulp. With these interpretations, the MTA and CEM cement showed better results than Biodentine in the terms of inflammatory pulp response.

The results of the present study showed that the pulp necrosis was not observed, which were in agreement with the observations of Katge and Patil [ 5 ] and Nowicka et al. [ 16 ]. In the study of Katge and Patil [ 5 ] on decayed human molar teeth, the direct pulp capping was performed with MTA and Biodentine and no necrosis was observed after 6 and 12 months of follow up. Nowicka et al. [ 16 ] evaluated the direct pulp capping with calcium hydroxide, Biodentine, MTA, and bonding system on the third human molar, and observed no necrosis in any of the teeth, although the pulp necrosis was seen after pulp capping with MTA in an animal study [ 23 ]. In this study, selected pulp vitality tests were used during the study period. The absence of pulp necrosis in the histological observation justifies the normal response of the tooth to periodic pulp vitality tests, and may indicate that the pulp vitality can be maintained with the presence of the healthy pulp at the start of treatment as well as the use of appropriate technique when working with each one of these capping materials. Therefore, it seems that the type of pulp capping material in maintaining the pulp vitality is less imperative. The results of this study showed that the highest percentage of samples in which the dentin bridge was formed was in the Biodentine group, but there was no significant difference in dentin bridge formation among Biodentine, CEM cement and MTA. This finding is similar to the findings by Katge and Patil [ 5 ], who found no significant difference in the dentin bridge formation between Biodentine and MTA within the six and twelve months. Nowicka et al. [ 16 ] reported that the highest dentin bridge formation was related to the Biodentine after pulp capping of the human third molar with calcium hydroxide, MTA, Biodentine and bonding system, but found no significant difference between the MTA and Biodentine in term of dentin bridge formation; which is similar to the result observed in this study. Madani et al. [ 19 ] also found no significant difference between MTA and CEM cement in term of dentin bridge formation, in an animal study.

The results of this study showed that the mean thickness of the dentin bridges produced in the Biodentine group was significantly higher than MTA and control groups, but there was no significant difference between CEM and MTA. Zarrabi et al. [ 15 ] compared the pulp responses after pulp capping of human premolar teeth using MTA and the CEM cement, and their results suggested that CEM cement compared to the MTA showed a thicker dentin bridge, but their difference was not significant, which is consistent with the results of the present study. In the study of Novick et al. [ 16 ], the maximum thickness of the dentin bridge was produced by Biodentine, followed by MTA, calcium hydroxide and bonding. They showed that the calcium silicate-based materials (Biodentine and MTA) have higher efficiencies in tissue repair than calcium hydroxide, which is probably due to the better stimulation of pulp stem cells by these materials. Tziafa et al. [ 17 ] also reported in an animal study that the dentin bridge thickness produced in Biodentine after three and eight weeks was significantly higher than the MTA, which is consistent with the findings of the present study.

In an animal study, researchers have shown that when comparing direct pulp capping with the Biodentine and MTA, the former material produces more pulp cell stimulation than MTA, which makes thickening of the dentin bridge and the highest amount of ectopic pulp calcification in developing teeth [ 17 , 24 ]. In this study, it should be noted that the pulp capping materials were placed on artificially exposed healthy pulp, and all conditions were ideal and controlled. The results of previous studies showed that the mechanical exposure of the pulp has a much more favorable prognosis and a higher success rate than caries exposure [ 4 , 10 ]. For this purpose, it is suggested that subsequent studies should be performed similar to actual clinical situations and in teeth with deep caries.

Conclusion

Although the dentin bridge formation and the thickness of the dentin bridge formed in the Biodentine group were higher than the other groups, the amount of pulp inflammation was also higher in contact with this substance. Since one of the main goals of vital pulp therapy is to reduce pulp inflammation and formation of the dentin bridge is not regarded as the success criterion per se, the results of this study suggest that MTA and CEM cement perform better when employed as the direct pulp capping material.

References

1. Nair PN, Duncan HF, Pitt Ford TR, Luder HU. Histological, ultrastructural and quantitative investigatio-ns on the response of healthy human pulps to experiment-al capping with mineral trioxide aggregate: a randomized controlled trial. Int Endod J. 2008; 41:128-50.
2. Ford TR, Torabinejad M, Abedi HR, Bakland LK, Kariyawasam SP. Using mineral trioxide aggregate as a pulp-capping material. J Am Dent Assoc. 1996; 127:1491-1494.
3. Parirokh M, Torabinejad M, Dummer P. Mineral trioxide aggregate and other bioactive endodontic cements: an updated overview- part I: vital pulp therapy. J Endod. 2018; 51:177-205.
4. Asgary S, Parirokh M, Eghbal MJ, Ghoddusi J. SEM evaluation of pulp reaction to different pulp capping materials in dog’s teeth. Iran Endod J. 2006; 1:117-123.
5. Katge FA, Patil DP. Comparative Analysis of 2 Calcium Silicate-based Cements (Biodentine and Mineral Trioxide Aggregate) as Direct Pulp-capping Agent in Young Permanent Molars: A Split Mouth Study. J Endod. 2017; 43:507-513.
6. Mehrdad L, Malekafzali B, Shekarchi F, Safi Y, Asgary S. Histological and CBCT evaluation of a pulpotomised primary molar using calcium enriched mixture cement. Eur Arch Paediatr Dent. 2013; 14:191-194.
7. Tziafas D, Smith AJ, Lesot H. Designing new treatment strategies in vital pulp therapy. J Dent. 2000; 28: 77-92.
8. Lee SJ, Monsef M, Torabinejad M. Sealing ability of a mineral trioxide aggregate for repair of lateral root perforations. J Endod. 1993; 19:541-544.
9. Ghorbani Z, Kheirieh S, Shadman B, Eghbal MJ, Asgary S. Microleakage of CEM cement in two different media. Iran Endod J. 2009; 4:87-90.
10. Asgary S, Eghbal MJ, Parirokh M, Ghanavati F, Rahimi H. A comparative study of histologic response to different pulp capping materials and a novel endodontic cement. Oral Surg Oral Med Oral Pathol Oral Radiol Endod. 2008; 106:609-614.
11. Khalil IT, Sarkis T, Naaman A. MM-MTA for direct pulp capping: a histologic comparison with ProRoot MTA in rat molars. J Contemp Dent Pract. 2013; 14:1019-1023.
12. Asgary S, Eghbal MJ, Parirokh M, Ghoddusi J, Kheirieh S, Brink F. Comparison of mineral trioxide aggregate&#039;s composition with Portland cements and a new endodontic cement. J Endod. 2009; 35:243-250.
13. Asgary S, Shahabi S, Jafarzadeh T, Amini S, Kheirieh S. The properties of a new endodontic material. J Endod. 2008; 34:990-993.
14. Tabarsi B, Parirokh M, Eghbal MJ, Haghdoost AA, Torabzadeh H, Asgary S. A comparative study of dental pulp response to several pulpotomy agents. Int Endod J. 2010; 43:565-571.
15. Zarrabi MH, Javidi M, Jafarian AH, Joushan B. Histologic assessment of human pulp response to capping with mineral trioxide aggregate and a novel endodontic cement. J Endod. 2010; 36:1778-1781.
16. Nowicka A, Wilk G, Lipski M, Kołecki J, Buczkowska Radlińska J. Tomographic Evaluation of Reparative Dentin Formation after Direct Pulp Capping with Ca(OH)2, MTA, Biodentine, and Dentin Bonding System in Human Teeth. J Endod. 2015; 41:1234-1240.
17. Tziafa C, Koliniotou Koumpia E, Papadimitriou S, Tziafas D. Dentinogenic responses after direct pulp capping of miniature swine teeth with Biodentine. J Endod. 2014; 40:1967-1971.
18. Borkar SA, Ataide I. Biodentine pulpotomy several days after pulp exposure: Four case reports. J Conserv Dent. 2015; 18:73-78.
19. Madani ZS, Haddadi A, Mesgarani A, Seyedmajidi M, Mostafazadeh A, Bijani A, et al. Histopathologic respon-ses of the dental pulp to calcium-enriched mixture (CEM) and Mineral Trioxide Aggregate (MTA) in diabetic and non-diabetic rats. Int J Mol Cell Med. 2014; 3:263-271.
20. Junn DJ, McMillan P, Bakland LK, Torabinejad M. Quantitative assessment of dentin bridge formation following pulp capping with mineral trioxide aggregate. J Endod. 1998; 24:278.
21. Faraco IM Jr, Holland R. Response of the pulp of dogs to capping with mineral trioxide aggregate or a calcium hydroxide cement. Dent Traumatol. 2001; 17:163-166.
22. American Academy of Pediatric Dentistry. Guideline on pulp therapy for primary and young permanent teeth.Pediatr Dent. 2004; 26 (7 Suppl): 115-119.
23. Manochehrifar H, Parirokh M, Kakooei S, Oloomi MM, Asgary S, Eghbal MJ, et al. The Effect of Mineral Trioxide Aggregate Mixed with Chlorhexidine as Direct Pulp Capping Agent in Dogs Teeth: A Histologic Study. Iran Endod J. 2016; 11:320-324.
24. De Rossi A, Silva LA, Gatón-Hernández P, Sousa-Neto MD, Nelson-Filho P, Silva RA, et al. Comparison of pulpal responses to pulpotomy and pulp capping with biodentine and mineral trioxide aggregate in dogs. J Endod. 2014; 40:1362-1369.
