Document Type: Original Article


1 Dept. of Oral and Maxillofacial Pathology, School of Dentistry, Shahid Beheshti University of Medical Sciences, Tehran, Iran

2 Dept. of Oral and Maxillofacial Pathology, School of Dentistry, Semnan University of Medical Sciences, Semnan, Iran

3 Dept. of Oral and Maxillofacial Pathology, Biomaterials Research Center, School of Dentistry, Shiraz University of Medical Sciences, Shiraz, Iran.


atement of the Problem: Mel-CAM (CD146, MUC18) is a 113-kD heterophilic cell-cell adhesion glycoprotein found in normal and tumoral tissues.
Purpose: The aim of this study is assessing the expression of Mel-CAM in common oral carcinomas like salivary gland mucoepidermoid carcinoma (MEC) and oral squamous cell carcinoma (OSCC) to differentiate the OSCC from high-grade MEC.
Materials and Method: This study was performed on 19 specimens of MEC and 17 specimens of OSCC, which were retrieved from the archive of Department of Pathology of Taleghani Hospital, Tehran, Iran. Immunohistochemical staining was performed by using antibody against CD146. The data was analyzed by using SPSS software through Mann-Whitney, Spearman's correlation coefficient, and Kruskal-Wallis tests.
Results: Mel-CAM was expressed in all MEC samples and 10 OSCC cases. The two groups were significantly different regarding the CD146 expression (p = 0.035). Furthermore, the CD146 expression was found to be significantly correlated with the invasion mode (p = 0.002), tumor size (p = 0.012), and histologic grade (p = 0.024) in OSCC group. No significant correlation existed between the expression, intensity and location with the histologic grade of MEC (p > 0.05). Nor was any significant correlation detected between the CD146 expression and lymph node metastasis in neither group.
Conclusion: Regarding the significant correlation between the CD146 expression and the prognostic factors in OSCC, this marker may predict the prognosis in OSCC patients, but not the MEC lesions. It cannot be used for differentiating high-grade MEC and OSCC.



Mucoepidermoid carcinoma (MEC) is one of the most common salivary gland malignancies that mainly affect the parotid. The tumor occurs within the second to the seventh decades of life, and is the most common malignant salivary gland tumor in children [ 1 ]. The biologic behaviors of MEC range from slow-growing mass to destructive rapidly growing mass [ 2 ]. Prognosis of the MEC is usually related to the clinical stage and histological grade [ 3 ]. Despite the advancements in diagnosis and treatment of high-grade MEC over the last two decades, the 5-year survival rate is still less than 50% [ 4 - 5 ]. High-grade MEC can be misdiagnosed for oral squamous cell carcinoma (OSCC), which is the most common malignancy of the oral cavity and accounts for al-most 2% of the cancer burden worldwide. The overall 5-year survival rate has not significantly increased in the last few years despite the advanced treatment modality [ 6 ]. Mel-CAM (CD146, MUC18) is a 113-kD heterophilic cell-cell adhesion glycoprotein, which belongs to the immunoglobulin supergene family [ 7 ]. It was initially identified as a marker of melanoma progression and metastasis [ 8 ]. This marker is primarily expressed by vascular endothelium and smooth muscle; but has also been detected in subpopulation of activated T lymphocytes, bone marrow, Schwann cells, ductal, and myoepithelial cells of the salivary glands [ 9 ].

Expression of Mel-CAM in tumor tissues is related to the tumor size, progression, metastatic potential, and aggressiveness [ 9 ]. Indeed, the biologic functions and role of the Mel-CAM as a diagnostic marker in pathology are now being recognized. The present study aims to assess the expression of Mel-CAM in salivary gland MEC and OSCC to find its possible correlation with the histological grade, tumor size, lymph node, and metastasis, besides its utility to differentiate the OSCC from high-grade MEC.

Materials and Method

Sample selection

The samples of this cross-sectional study were 36 formalin-fixed, paraffin-embedded tissue blocks including 17 cases of OSCC and 19 cases of MEC, which were obtained from the archive of the Department of Pathology of Taleghani Hospital, affiliated to Shahid Beheshti University of Medical Sciences, Tehran, Iran. Anonymity of the patients’ records was strictly respected.

Hematoxylin and eosin (H&E) stained sections were used to confirm the diagnosis. Clinicopathologic information of each case including age, sex, tumor location, and histological grade were collected from the patients' records and reviewing slides. For OSCC samples, mode of invasion was also identified. Cases with incomplete data, insufficient paraffin-embedded tumor material, inappropriate fixation, and incisional biopsy were excluded.

Immunohistochemistry (IHC)

Sections of 4-µm thickness were cut from all samples and mounted on silane-coated slides. The sections were deparaffinized with 100% xylene and rehydrated in graded ethanol series. Sections were immersed in Tris-buffered saline (TBS) with a pH of 6.0, and heated in a microwave oven at 750 watts for antigen retrieval. After cooling into room temperature, the sections were incubated with primary antibody (Anti-CD146, monoclonal mouse Anti-Human clone: AA1, Ready to use, ABcam, USA) at 1:2000 for an hour. Having been washed in TBS, the sections were treated with Dako EnVision (Dako, Germany). The DAB chromogen was applied to visualize the antibody expression, and then, counterstained with Mayer’s hematoxylin. Normal parotid salivary gland was used as positive control.

Evaluation of IHC

CD146 immunoreaction in the tumoral cells was determined in 10 randomly-selected fields by counting all the positive cells in each field according to the median index of positive cells obtained from 10 high-power fields (HPF) and scored as negative (0-5%), weak (6-25%), moderate (26-50%) and strong (51-100%) [ 10 ]. The staining intensity was evaluated as 0=no positive cells, += mild, ++= moderate, +++= strong [ 11 ]. Mode of inv-asion in OSCC samples was assessed on the H&E slides according to Jacobson method (scored I to IV) [ 12 ].

According to WHO classification (2005), the histopathologic grade of OSCC samples was classified into well-, moderate- and poorly-differentiated. The histopathologic grade of the MEC was categorized as low, intermediate and high grade based on Auclair classification [ 10 ]. All slides were evaluated by two pathologists.

Statistical analysis

The statistical analysis was carried out on the tabulated data by using SPSS software, version 18.0 (SPSS Inc., Chicago, IL, USA). Mann-Whitney test was used to assess the correlation between CD146 expression and the clinicopathologic variables including age, histological grade, nodal metastasis, and mode of invasion. Spearman's correlation coefficient and Kruskal-Wallis test were done to determine the correlation of CD146 expression with the tumor size and expression location, respectively. The significance level of all tests was set at 0.05. All the procedures performed in the current study were approved by the Ethics Committee of Shahid Beheshti University of Medical Sciences (#9204) in accordance with the Declaration of Helsinki (1964) and its later amendments. Formal written informed consent was not required with a waiver by the Ethics Committee of Shahid Beheshti University of Medical Sciences.


The samples were 23 men and 13 women (Table 1). CD146 was expressed in all MEC samples as cytoplasmic and membranous staining.

Variables MEC OSCC
Sex Male 10 13
Female 9 4
Age(Mean±SD) 45.58±14.31 64.76±9.28
Site of tumor Alveolar mucosa 6 6
Parotid 5
Sublingual 1
Tongue 7
Hard palate 5
Flour of the mouth 2
Other sites 2 2
Histopathologic grade High grade 7 3
Moderate grade 10 3
Low grade 2 11
Size(Cm) Range (mean) 2.68-3.56 (2.86) 3.5-6.12 (5.08)
Lymph node
Yes 2 (10.5%) 5 (29.5%)
No 17(89.5%) 12(70.5%)
Mode of invasion*
I 9
II - 0
IV 4
*Mode of invasion was classified only for OSCC
Table 1.Characteristics of MEC and OSCC patients.

The CD146 immunoexpression was strong in 78.9% (n=15), moderate in 5.3% (n=1), and weak in 15.8% (n=3) of cases (Figure 1 and 2). In OSCC samples, 10 cases expressed CD146, out of which 47.1% (n=8) was strong and 11.8% (n=2) were weak (Figure 3 and 4). The two groups were significantly different in terms of CD146 expression (p< 0.035). No significant correlation was detected between the CD146 expression, intensity, and location with the histological grade in MEC group (p> 0.05).

Figure 1. Cytoplasmic and membranous staining of epidermoid cells in mucoepidermoid carcinoma, moderate intensity (CD146 IHC stain, 400 X)

Figure 2. Cytoplasmic and membranous staining of mucous cells in mucoepidermoid carcinoma, strong intensity (CD146 IHC stain, 200 X)

Figure 3. Cytoplasmic and membranous staining of squamous cells in squamous cell carcinoma, moderate intensity (CD146 IHC stain, 400 X)

Figure 4. Cytoplasmic and membranous staining of squamous cells in squamous cell carcinoma, strong intensity (CD146 IHC stain, 400 X)

However, in the OSCC group, the intensity and expression of CD146 was significantly correlated with the histopathological grade of OSCC. Meanwhile, the CD146 expression was not significantly correlated with the lymph node metastasis in neither group. Moreover, a significant correlation existed between the CD146 expression and the mode of invasion and tumor size in the OSCC cases (p< 0.05) (Table 2).

Variables CD146 expression in MEC CD146 expression in OSCC
Metastasis 0.338 0.442
Size 0.649 0.012
Mode of invasion - 0.002
Histologic grade 0.726 0.024
p< 0.05 is significant
Table 2.Correlation of CD146 expression in MEC and OSCC with clinicopathologic findings.


The correlation between the CD146 expression and the clinical behavior and lymph node metastasis has been evaluated in some tumors such as melanoma, breast carcinoma, and prostate carcinoma. The present study tried to investigate if the expression of CD146 in MEC and OSCC samples is associated with the histological grade, lymph node metastasis, tumor size, and mode of invasion in these tumors.

In this study, the immunohistochemical expression of CD146 was observed in all MEC samples; the staining was strong in 78.9% of samples, which was in accordance with Pires et al.'s findings [ 10 ]. The present study detected no significant correlation between the staining intensity and histological grade of the tumor. It was in agreement with Pires et al.'s study [ 10 ] and in contrast with Zhang’s [ 11 ] and Li’s[ 12 ] findings, who studied the CD146 expression in breast carcinoma and malignant cervix tumor. The difference between the studies might be attributed to the type of investigated tumors.

In high-grade MEC, the staining intensity was moderate in 57.1% and strong in 42.9% of samples. Yet, the correlation between the CD146 staining intensity and the histopathologic grade of MEC was not significant. The staining localization was mostly in the cytoplasm of mucous and epidermoid cells. No significant correlation was found between the staining localization and the histopathologic grade in MEC cases.

CD146 was expressed in 58.9% of OSCC cases, which disagreed with what was found by Pires et al. [ 10 ], who reported the CD146 expression in none of the OSCC samples in his study. This difference might be due to the different staining method and the smaller sample size in Fabio’s study [ 10 ]. In OSCC samples, strong staining was seen in all tumors with histopathologic grade III, which was statistically significant and in line with Zhang et al.'s study [ 11 ].

No significant correlation was detected between the staining intensity and lymph node metastasis (p> 0.05).

Our findings were in contrast with Zhang et al. [ 11 ] and Wu et al. [ 13 ] studies on cervix, ovarian, and prostate tumors. The difference might be due to the different type of tumors and the smaller sample size in current study. Our findings revealed that the CD146 expression cannot predict lymph node metastasis in MEC and OSCC but it did in prostate, ovarian tumors, and colorectal cancers [ 14 ]. In addition, Li et al. [ 15 ] noted that the CD146 expression was an indicator of poor prognosis in esophageal SCC.

Some studies documented the role of α7β3 integrin as a ligand of Mel-CAM and accredited that α7β3 integrin in adults' normal tissues are limited to basolateral membrane cells in ductal epithelium of parotid glands [ 16 ]. Seemingly, the integrin is expressed in normal and benign tumors; but in malignant tumors, it either remains unexpressed or undergoes structural changes, which further lead to dysfunction and lack of connection between the neoplastic cells [ 16 ].

Mesenchymal and epithelial interactions are essential for glandular organ formation in salivary glands. Moreover, the role of CD146 in epithelial-mesenchymal transition in breast cancer has been alluded [ 17 ]. Evidence shows that absence or decrease of CD146 expression in breast cancer leads to repair connections between the normal cells and waste connections between the tumoral cells, and acts as a suppressor in breast tumor [ 18 ]. The low expression of CD146 in normal tissue and benign tumor is used for differential diagnosis of some benign and malignant tumors with similar origin (malignant mesothelioma and reactive one) [ 19 ]. The present study detected a significant relation between the tumor size and CD146 expression (p= 0.012). OSCC samples of larger than 6.1 cm showed higher expression, which was in accordance with Mills’s in vivo study on melanoma cells [ 20 ]. Other in vivo studies have asserted the role of CD146 in aggressive behavior of melanoma cells. Likewise, MMP-2 regulation and inhibition of CD146 correlate with less aggressiveness and high apoptotic activity [ 18 ]. The current study detected a significant correlation between the histological grade of OSCC and CD146 expression, staining intensity, and localization of staining. These variables had never been evaluated before. Additionally, the mode of invasion was significantly correlated with high expression and intensity of CD146 in OSCC, indicating the imperative role of CD146 in tumor development and invasion. Regarding the correlation between CD146 expression and mode of invasion, the present res ults suggest that CD146 expression is a more determining indicator of mode of invasion in OSCC than MEC cases. However, further studies with larger sample sizes may introduce CD146 as an advantageous prognostic marker in OSCC.


CD146 expression is significantly correlated with the mode of invasion, tumor size, and histological grade in oral squamous cell carcinomas. It may help predict the prognosis in patients with OSCC but not MEC. CD146 is not a useful marker for differentiating between the high-grade MEC and OSCC.


  1. Neville BW. . Oral &amp; maxillofacial pathologyy. 4th ed. Missouri: Elsevier St. Louis; 2016. p. 454-455.
  2. Joseph A. Oral pathology clinical pathologic correlations. 7th ed. Missouri: Elsevier St. Louis; 2017. p. 209-210.
  3. Brandwein MS, Ivanov K, Wallace DI, Hille JJ, Wang B, Fahmy A, et al. Mucoepidermoid carcinoma: a clinicopathologic study of 80 patients with special reference to histological grading. Am J Surg Pathol. 2001; 25:835-845.
  4. Ali S, Sarhan M, Palmer FL, Whitcher M, Shah JP, Patel SG, et al. Cause-specific mortality in patients with mucoepidermoid carcinoma of the major salivary glands. Ann Surg Oncol. 2013; 20:2396-2404.
  5. McHugh CH, Roberts DB, El-Naggar AK, Hanna EY, Garden AS, Kies MS, et al. Prognostic factors in mucoepidermoid carcinoma of the salivary glands. Cancer. 2012; 118:3928-3936.
  6. Warnakulasuriya S. Global epidemiology of oral and oropharyngeal cancer. Oral Oncol. 2009; 45: 309-316.
  7. Shih IM. The role of CD146 (Mel-CAM) in biology and pathology. J Pathol. 1999; 189:4-11.
  8. Lehmann JM, Riethmüller G, Johnson JP. MUC18, a marker of tumor progression in human melanoma, shows sequence similarity to the neural cell adhesion molecules of the immunoglobulin superfamily. Proc Natl Acad Sci USA. 1989; 86:9891-9895.
  9. Shih IM, Nesbit M, Herlyn M, Kurman RJ. A new Mel-CAM (CD146)-specific monoclonal antibody, MN-4, on paraffin-embedded tissue. Mod Pathol. 1998; 11:1098-1106.
  10. Pires FR, Shih IeM, da Cruz Perez DE, de Almeida OP, Kowalski LP. Mel-CAM (CD146) expression in parotid mucoepidermoid carcinoma. Oral Oncol. 2003; 39:277-281.
  11. Zhang H, Zhang J, Wang Z, Lu D, Feng J, Yang D, et al. CD146 is a potential marker for the diagnosis of malignancy in cervical and endometrial cancer. Oncol Lett. 2013; 5:1189-1194.
  12. Li W, Yang D, Wang S, Guo X, Lang R, Fan Y, et al. Increased expression of CD146 and microvessel density (MVD) in invasive micropapillary carcinoma of the breast: Comparative study with invasive ductal carcinoma-not otherwise specified. Pathol Res Pract. 2011; 207:739-746.
  13. Wu GJ, Fu P, Chiang CF, Huss WJ, Greenberg NM, Wu MW. Increased expression of MUC18 correlates with the metastatic progression of mouse prostate adenocarcinoma in the TRAMP model. J Urol. 2005; 173:1778-1783.
  14. Tian B, Zhang Y, Li N. CD146 protein as a marker to predict postoperative liver metastasis in colorectal cancer. Cancer Biother Radiopharm. 2013; 28:466-470.
  15. Li Y, Yu JM, Zhan XM, Liu LL, Jin N, Zhang YX. Correlation of CD146 expression and clinicopathological characteristics in esophageal squamous cell carcinoma. Oncol Lett. 2014; 8:859-863.
  16. Charalabopoulos K, Mittari E, Golias C, Peschos D, Batistatou A. Integrin receptors and extracellular matrix components in parotid neoplasms. Exp Oncol. 2005; 27:2-6.
  17. Zeng Q, Zhang P, Wu Z, Xue P, Lu D, Ye Z, et al. Quantitative proteomics reveals ER-α involvement in CD146-induced epithelial-mesenchymal transition in breast cancer cells. J Proteomics. 2014; 103:153-169.
  18. Ouhtit A, Gaur RL, Abd Elmageed ZY, Fernando A, Thouta R, Trappey AK, et al. Towards understanding the mode of action of the multifaceted cell adhesion receptor CD146. Biochim Biophys Acta. 2009; 1795:130-136.
  19. Sato A, Torii I, Okamura Y, Yamamoto T, Nishigami T, Kataoka TR, et al. Immunocytochemistry of CD146 is useful to discriminate between malignant pleural mesothelioma and reactive mesothelium. Mod Pathol. 2010; 23:1458-1466.
  20. Mills L, Tellez C, Huang S, Baker C, McCarty M, Green L, et al. Fully human antibodies to MCAM/MUC18 inhibit tumor growth and metastasis of human melanoma. Cancer Res. 2002; 62:5106-5114.
