Document Type : Case Series


1 Dept. of Oral and Maxillofacial Surgery, School of Dentistry, Tehran, University of Medical Sciences, Tehran, Iran. Craniomaxillofcial Research Center, Tehran University of Medical Sciences, Tehran, Iran.

2 Dentist, School of Dentistry, Tehran University of Medical Sciences, Tehran, Iran.



The use of dental implants to restore edentulous jaws has become commonplace. Usually, in the maxilla, following a tooth extraction, the height of alveolar bone decreases. This alteration in bone increases the risk of implants migrating into the sinus. In general, Caldwell-Luc and endoscopic surgery are performed to retrieve dental implants. In this case series, we collected data from 39 patients who had the complication of implant displacement within the maxillary sinus for 25 years. All the implants were removed using the Caldwell-Luc technique. Implant migration happened following functional loading, during the prosthetic procedure, due to lack of osseointegration in 3 patients, and during implant placement into the fresh socket in 3 patients. In the remaining cases, migration occurred preoperatively or postoperatively and prior to implant loading. Insufficient bone quantity is sometimes causing the implant to migrate to the maxillary sinus. In case of minimal bone height, a sinus lift before implant placement should be conducted. Retrieval of an implant pushed inside the maxillary antrum using the Caldwell Luc approach proved to be a reliable technique.


Farnoosh Razmara (Google Scholar)


  • Deva*Meena S, Dinesh D S, Lakshmi Devi G, Shanmugavadivel G. Sinus lift procedures in dental implants: A literature review on techniques, recommendations, and complications. Indian J Dent Sci. 2020; 12: 180-186.
  • Ding X, Wang Q, Guo X, Yu Y. Displacement of a dental implant into the maxillary sinus after internal sinus floor elevation: report of a case and review of literature. Int J Clin Exp Med. 2015; 8: 4826.
  • Mumtaz M, Alotaibi NM, Alfawaz NF, Alhajri AN. Retrieval of two displaced dental implants from the maxillary sinus through Caldwell-Luc approach: A case report. Int J of Med Dent Case Reports. 2020; 2020: INS161200420.
  • Sgaramella N, Tartaro G, D'Amato S, Santagata M, Colella G. Displacement of dental implants into the maxillary sinus: a retrospective study of twenty‐one patients. Clin Implant Dent Relat Res. 2016; 18: 62-72.
  • Jensen OT. Report of the sinus consensus conference of 1996. Int J Oral Maxillofac Implants Quint Dent Implant. 1999; 6: 330-352.
  • An JH, Park SH, Han JJ, Jung S, Kook MS, Park HJ, et al Treatment of dental implant displacement into the maxillary sinus. Maxillofac Plast Reconstr Surg. 2017; 39: 1-5.
  • Manor Y, Anavi Y, Gershonovitch R, Lorean A, Mijiritsky E. Complications and Management of Implants Migrated into the Maxillary Sinus. Int J Periodontics Restorative Dent. 2018; 38: e112-e118.
  • Maciel J, Borrasca AG, Delanora LA, de Sá Simon ME, de Araujo NJ, Faverani LP, et al. Maxillary sinus implant removal: modified Caldwell-Luc technique. Res Soc Dev. 2020; 9: e901997936.
  • Huang IY, Chen CM, Chuang FH. Caldwell-Luc procedure for retrieval of displaced root in the maxillary sinus. Oral Surg Oral Med Oral Pathol Oral Radiol Endod. 2011; 112: e59-e63.
  • Fonseca, RJ, Marciani RD, Turvey TA. Oral and maxillofacial surgery. 3rd ed. St. Louis: Mo, Saunders, Elsevier; 2018. p. 302.
  • Gnigou M, Goutzanis L, Sarivalasis S, Petsinis V. Retrieval of displaced implants inside the maxillary sinus: two case reports and a short review. Int J Implant Dent. 2019; 5: 1-8.
  • Jeong KI, Kim SG, Oh JS, You JS. Implants displaced into the maxillary sinus: a systematic review. Implant Dent. 2016; 25: 547-551.
  • Hamdoon Z, Mahmood N, Talaat W, Sattar AA, Naeim K, Qais A, et al Evaluation of different surgical approaches to remove dental implants from the maxillary sinus. Sci Rep. 2021; 11: 4440.
  • Eltas A, Dundar S, Eltas SD, Altun O, Yolcu U, Saybak A. Accidental displacement of dental implants into both maxillary sinuses during surgery. J Oral Implantol. 2015; 41: 601-603.
